tie rod end


TIE ROD END

hyundai

model : 90A 520 TIE ROD END

  • no.

  • 8-138
    8-139
  • DIMENSIONS

  • L=172
    M42P1.5
    m24P1.5
    K=31.5
    k=29.2
  • REMARK

  • R/L
    56890-92100
    56880-92100

TIE ROD END

hyundai

model : 91A 540 TIE ROD END

  • no.

  • 8-140
    8-141
  • DIMENSIONS

  • L=172
    M42P1.5
    m24P1.5
    K=30.2
    k=27.7
  • REMARK

  • R/L
    56890-69000
    56880-69000

TIE ROD END

hyundai

model : 520 TIE ROD END

  • no.

  • 8-159
    8-160
  • DIMENSIONS

  • L=172
    M42P1.5
    m24P1.5
    K=28.2
    k=25.5
  • REMARK

  • R/L

TIE ROD END

hyundai

model : 540 TIE ROD END

  • no.

  • 8-161
    8-162
  • DIMENSIONS

  • L=172
    M42P1.5
    m24P1.5
    K=30.2
    k=27.7
  • REMARK

  • R/L

TIE ROD END

hyundai

model : 5T AEROTOWN TIE ROD END

  • no.

  • 9-172-4
    9-172-5
  • DIMENSIONS

  • L=112
    M27P1.5
    m18P1.5
    K=22.3
    k=20
  • REMARK

  • R/L
    56890-62000
    56880-62000

TIE ROD END

hyundai

model : 5T EG TIE ROD END

  • no.

  • 9-172-6
    9-172-7
  • DIMENSIONS

  • L=149
    M32P1.5
    m20P1.5
    K=24
    K=22
  • REMARK

  • R/L
    56890-6A001
    56880-6A001

TIE ROD END

hyundai

model : MIGHTY2 TIE ROD END

  • no.

  • 9-172-16
    9-172-17
  • DIMENSIONS

  • L=106
    M22P1.5
    m14P1.5
    K=21.1
    K=18.5
  • REMARK

  • R/L
    56890-5H000
    56880-5H000

TIE ROD END

hyundai

model : AEROTOWN TIE ROD END

  • no.

  • 9-172-22
    9-172-23
  • DIMENSIONS

  • REMARK

  • R/L

TIE ROD END

hyundai

model : 5T MEGA TRUCK TIE ROD END

  • no.

  • 9-172-25
    9-172-26
  • DIMENSIONS

  • REMARK

  • R/L
    56890-6B000
    56880-6B000

TIE ROD END

hyundai

model : HD 24T TIE ROD END

  • no.

  • 9-172-27
    9-172-28
  • DIMENSIONS

  • REMARK

  • R/L
    56890-7F500
    56880-7F500

TIE ROD END

hyundai

model : AEROSPACE TIE ROD END

  • no.

  • 10-192-3
    10-192-4
  • DIMENSIONS

  • REMARK

  • R/L
    56890-8A500
    56880-8A500

TIE ROD END

hyundai

model : AEROAPACE STABILIZER TIE ROD END (F)

  • no.

  • 10-193
  • DIMENSIONS

  • REMARK

  • R/L
    54740-8A801

TIE ROD END

hyundai

model : 71A TIE ROD END

  • no.

  • 9-172-2
    9-172-2-1
  • DIMENSIONS

  • L=179
    M48P1.5
    m18P1.5
    K=24.5
    K=22.5
  • REMARK

  • R/L
    MC806270
    MC806271

TIE ROD END

hyundai

model :E-MIGHTY
TIE ROD END

  • no.

  • 9-172-39
    9-172-40
  • DIMENSIONS

  • L=130
    M24P1.5
    m16P1.5
    K=22
    K=20
  • REMARK

  • R/L
    56890-5K000
    56880-5K000

TIE ROD END

hyundai

model : POWERTECH TIE ROD END

  • no.

  • 9-175-1
    9-175-2
  • DIMENSIONS

  • L=164
    M42P1.5
    m24P2
    K=30.5
    K=27.6
  • REMARK

  • R/L
    56890-7G300
    56880-7G300

TIE ROD END

hyundai

model :AERO EXPRESS QUEEN TIE ROD END

  • no.

  • 10-192-7
    10-192-8
  • DIMENSIONS

  • REMARK

  • R/L
    56890-8A100
    56880-8A100

TIE ROD END

hyundai

model : POWERTECH NEW TIE ROD END

  • no.

  • 9-175-1
    9-175-2
  • DIMENSIONS

  • REMARK

  • R/L
    56890-7E000
    56880-7E000

TIE ROD END

hyundai

model : LIBERO, PORTER2 TIE ROD END

  • no.

  • 9-172-59
  • DIMENSIONS

  • REMARK

  • R/L
    56820-47500

TIE ROD END

hyundai

model : STAREX07 TIE ROD END

  • no.

  • 9-172-50
    9-172-51
  • DIMENSIONS

  • REMARK

  • R/L
    56820-4H100
    56820-4H000

TIE ROD END

hyundai

model : GRACE95 STAREX97 PORTER TIE ROD END

  • no.

  • 9-172-52
  • DIMENSIONS

  • REMARK

  • R/L
    56872-43010

TIE ROD END

hyundai

model : GRACE95 PORTER95 AXEL JOINT TIE ROD END

  • no.

  • 9-172-53
  • DIMENSIONS

  • REMARK

  • R/L
    57730-4B000

TIE ROD END

hyundai

model : PORTER2-04 AXEL JOINT TIE ROD END

  • no.

  • 9-172-54
  • DIMENSIONS

  • REMARK

  • R/L
    57730-4F000
